Just wondering, the new power link seems bigger and uglier than the prototype. What happened? why is that?







before anyone comments that the classy is a bigger card, indeed it is, but its still a two slot design like the regular ftw so, just wondering why it got so fat and more ugly;]


MAXIMUS 7 HERO / i7 4790K - H110i GT / 16GB DDR3 / EVGA 1080 TI Fe/ Xonar Phoebus / XFX 850w Gold+ / WD Black 5 TB / Evolv Glass / Dell u2713HM

#1

2 Replies Related Threads

    WhatGravitas
    New Member
    • Total Posts : 21
    • Reward points : 0
    • Joined: 2016/04/05 14:50:13
    • Status: offline
    • Ribbons : 0
    Re: Power Link Prototype and Final version 2016/11/16 15:05:15 (permalink)
    As far as I can tell: adaptability happened.

    Look at this shot of the prototype below:

    (from Bitwit's Computex coverage)

    The power link is much thinner but also doesn't have the rail system of the finished product. Without the rail, it will only work for cards with two 8-pins and the power sockets in exactly the same spot as the 1080/1070 FTW/Classified.

    The bulkier version, however, will work for almost any card (as long as the polarity is the same as on nVidia's reference cards, like on EVGA's cards).
    #2
    velo-x
    New Member
    • Total Posts : 97
    • Reward points : 0
    • Joined: 2016/06/29 14:15:03
    • Status: offline
    • Ribbons : 1
    Re: Power Link Prototype and Final version 2016/11/16 15:17:53 (permalink)
    Makes sense, true.

    Still sad its uglier, the old one was much nicer.
