Hi to all,
this is my first post and I'm sorry for my english... I'm Italian.

I found this thread interesting so much but I've not seen yet an E762 BIOS Template. So this is the mine:

Mother Board ( EVGA X58 Classified E762 )
Drivers ( Intel 9.1.1.1025 )
Bios ( 51 )
BIOS Date ( 3-31-2010 )
BIOS File ( E76251.bin )
CPU ( Intel Core i7 980X Extreme Edition )
CPU Cooler ( Standard Stock Cooling with Arctic Silver 5)
Memory ( 6GB Corsair Dominator GT 2000C8 )
PSU ( Silverstone Strider 1500W )
GPU ( Sapphire HD4650 1GB )
Drivers ( ATI Catalyst 10.3 )
Operating System ( Microsoft Windows 7 Ultimate x64 )

Frequency Control
Dummy O.C ( Disabled )
Extreme Cooling ( Disabled )
CPU Clock Ratio ( 20X )
CPU Host Frequency(Mhz) ( 200 )
MCH Strap ( Auto )
CPU Uncore Frequency(Mhz) ( 4006Mhz [20X] )
CPU Clock Skew ( 0 ps )
Spread Spectrum ( Disabled )
PCIE Frequency(Mhz) ( 100 )
OC Recorvery ( Disabled )
Turbo Performance ( Diasbled )

Memory Feature
Memory Speed ( Standard )
Memory Control Setting (Enabled )
Memory Frequency ( 1333Mhz / 2:10 )
Channel Interleave Setting ( 6 way )
Rank Interleave Setting ( 4 way )
Memory Low Gap ( Auto )
tCL Setting ( 8 )
tRCD Setting ( 8 )
tRP Setting ( 8 )
tRAS Setting ( 24 )
tRFC Setting ( 74)
Command Rate ( 1T )
... ( Auto )

Voltage Control
EVGA VDroop Control ( Without VDroop )
CPU VCore ( 1.25000V )
CPU VTT Voltage ( +200mV )
CPU PLL VCore ( 1.80000V )
IOH PLL VCore ( 1.80000V )
QPI PLL VCore ( 1.10000V )
DIMM Voltage ( 1.52000V )
DIMM DQ Vref ( +0mV )
IOH VCore ( 1.10000V )
IOH/ICH I/O Voltage ( 1.50000V )
ICH VCore ( 1.10000V )
NF200 Voltage ( 1.20000V )
VTT PWM Frequency ( 250 KHz )
CPU PWM Frequency ( 800 KHz )
CPU Impedance ( Auto )
DDR Signal 0 ( +0 )
DDR Signal 1 ( +0 )
DDR Signal 2 ( +0 )
CPU Signal ( -53 )
QPI Signal 0 ( +0 )
QPI Signal 1 ( +0 )
QPI Signal 2 ( +0 )
PCIE Signal 0 ( +0 )
PCIE Signal 1 ( +0 )

CPU Feature
Intel SpeedStep ( Disabled )
Turbo Mode Function ( Enabled )
CxE Function ( Disabled )
Execute Disable Bit ( Enabled )
Virtualization Technology ( Disabled )
Intel HT Technology ( Enabled )
Active Processor Cores ( All )
QPI Control Settings ( Enabled )
QPI Link Fast Mode ( Enabled )
QPI Frequency Selection ( 4.800 GT/s )

There are many things that I don't understand, for example: why many people disable "Execute Disable Bit"? Is the impact on performance so important? Or it limits the overclock in anyway?

For now this is my first test on stock cooling and ambient temperature of 24/25°C:


What do you think about?

Ok guys im not sure if anyone can help but I have been struggling with voltages for some time now. If anyone has any leads for me as to what could be causing this problem I would be so happy to figure it out. My system is requiring extremely high voltages to run a overclock and it has been this way even with my 920 D0 so I am pretty sure it is not my chip unless I have the bad luck of getting bad chip after bad chip. I have composed a list of minimum voltages I can boot into windows with at each clock. Keep in mind that this list is a minimum voltages meaning that they are not stable just what I can boot into windows with. For example I can boot into windows at 4.4Ghz at 1.4375Vcore but it isn't stable unless I bumb my Vcore to 1.535V so keep that in mind when you are looking at these voltages. To run this test I down clocked my memory to its lowest setting so it would not be a conflicting issue. I would also like to note I upgraded to a Corsair Dominator GT 2000mHz kit and it didnt solve my problem. In fact I fell like it has only made matters worst because in order for me to run my ram at 2000Mhz/143Blck I cant even boot into windows unless I am running 4.5V CPU VTT.

My list of minimum Vcore required to boot into windows Turbo/on:

28X - 133Blck = 3733Mhz - 1.225Vcore
29X - 133Blck = 3866Mhz - 1.275Vcore
30X - 133Blck = 4000Mhz - 1.300Vcore
31X - 133Blck = 4133Mhz - 1.3375Vcore
32X - 133Blck = 4266Mhz - 1.3875Vcore
33X - 133Blck = 4400Mhz - 1.4375Vcore - (1.535Vcore stable)
34X - 133Blck = 4533Mhz - 1.50625Vcore
35X - 133Blck = 4666Mhz - 1.56875Vcore


Evga 3X SLI 132-BL-E758-TR / Bios 49
i7 980x
6GB Corsair Dominator GT 2000mHz 8-8-8-24
2 x GTX 295 CO-OP
Thermaltake Toughpower 1200W PSU
4 x 150GB Veloci Raptor Hard Drives - Raid-0
1 x 1.5TB Seagate Barracuda
APC Back-UPS XS 1500
Windows 7 Home Premium 64-bit

Ya right now I am at 1866 and it seems to be doing fine with 3.75 VTT

Yup I have tried upping the blck and changing the multiplier. Though I haven't messed around with it too much I have tried your template along with everyone else on here. It just seems that no matter what I do I have to pump out a massive amount of Vcore and CPU VTT compared to everyone else. My temps are ok I mean I haven't done too much stress testing due to stability issues but from what I have seen my hottest core hasn't reached 60c yet so I am not too worried with the temps. At idle my CPU shows up as 20C in E-Leet and my hottest CPU core is around 39C. at load my CPU is usually in the 40C area. My VREG is cooking though. It has hit 105C in stress testing even at stock clocks. I have tried lowering the QPI frequency but only if I raise the Blck.

sgtharry

Have you tried upping the Bclk and dropping the multiplier? For some STUPID reason mine is more stable with 167X27 than 145X31, they both equal 4.5. Also, have you tried setting QPI frequency to 4.80 GT/s?  How are your temps? Are you watercooled? If your temps don't get over 80c while Stress testing, you're fine.

Why is that stupid? Higher multi, lower bclk, makes perfect sense. Also, no need really to short change yourself with a setting of 4.8 GT/s vs. 6.4, I'd look elsewhere for adjustment.

Productive in what way?  I have seen no improvement in Gflops, or Vantage cpu score going from 4.8 to 6.4. My machine will not boot with that setting unless i'm under 147 Bclk. The 6.4 is for stock Bclk. I believe. Doesn't my 4.8 increase as I up the Bclk? No way of seeing this anywhere. I'm PRETTY sure i'm over 6.4 GT/s with my 167 Bclk. setting, and 4.8 GT/s. in the bios. Correct me if i'm wrong.

Thanks, That explains alot for my no boot thing. It's probably over 6.4GT/s with my 167 Bclk when i'm set at 4.80. Is there any way you can see this?

Ahh, I never looked in Everest. Will look when I get home. Thanks

It takes less strain off the system and uses less voltage to keep the host cpu frequency around 133Mhz and just use the multiplier. I also run my ram at 6-6-6-24-68@1650Mhz and only needs 1.275 VTT to do so. I found no benefit running the ram at 2000Mhz and it added lots of heat because of the extra VTT voltage needed.

Hi.  I'd like to use a 980X with multiplier at 27 or 28 (preferably 28), and go with a good 1333 memory.  What bios changes would be needed with the Classified, and would those changes be close to the same with other high-end motherboards such as Rampage II Extreme, MSI, etc.?  Don't know much about it, but it seems that changing the cpu to 28 and the memory multiplier to 10 would not be too difficult, but I don't know.  Cooling would be a Prolimatech, True 120 or similar.
Thanks much.

What I was thinking was an overclock to around 3.74 with the memory at 1333, and I also thought (wrongly, it looks like) that all you'd have to do was increase the 980's multiplier to 28 and change the memory multiplier to 10.  Looks like it's a whole lot more complicated than that.

Oh, well, back to the drawing board.

Thanks much for the info.

reply to msg #52 this is what i hade before i bought and built this new rig
Manufacturer: alienware
Processor: Intel(R) Core(TM)2 Duo CPU E8200 @ 2.66GHz (2 CPUs), ~4.0GHz
Memory: 2558MB RAM
Hard Drive: 892 GB Total
Video Card: 2x NVIDIA GeForce BFG GTX 280 OCX
Monitor: SyncMaster 2032BW/2032GW,SyncMaster Magic CX2032GW(Digital)
Sound Card: Speakers (Realtek High Definition Audio)
Speakers/Headphones:
Keyboard: USB Root Hub
Mouse: Logitech HID-compliant G9 Laser Mouse
Mouse Surface: alienware mouse mat
Operating System: Windows 7 Ultimate 64-bit (6.1, Build 7600) (7600.win7_rtm.090713-1255)
Motherboard: Evga nforce 680i
Computer Case: Alienware Predator 2 Case
just looking thru this thread for a system that's a close match to mine before I oc it. Looking for a 4.5GHz stable oc the now, but that will change to closer to 5GHz in a few months.

No, dangerous is above 1.74

Heres my Overclock the now will get a Template up tomorrow

 Get your oc on your cpu before trying to run your ram at 2000Mhz. You really need to lower your VTT voltage its crazy high.
